Identify the maker, exact set, and keyboard revision before buying LSA keycaps. Keychron defines LSA as Low Profile Spherical Angled, while 3dkeycap sells a separate resin LSA design for split keyboards. The shared name does not establish interchangeable geometry or complete kit coverage. Start with the Keychron Version 2 product identity or the 3dkeycap split set, then check the selected package against your board.
This guide is for buyers replacing caps on a Keychron low-profile keyboard or ordering a split-board set. It compares product specifications and seller descriptions captured October 15, 2026; it does not report hands-on fit, sound, or typing tests.
Quick buying rules
- Record the complete product name and version before comparing colors.
- Check your keyboard’s revision and layout against that exact set’s compatibility statement.
- Treat material, legend production, and shine-through lighting as separate specifications.
- Confirm every required key and mounting position before placing an order.
Jump to:
- Identify the product and shape
- Compare LSA sets
- Check Keychron revisions
- Complete the fit worksheet
- Check the resin split set
- Review the selected offer
- Frequently asked questions
Identify the product and shape
For Keychron products, LSA means Low Profile Spherical Angled. That gives you the manufacturer’s profile name, but it does not supply a numerical height, row angle, or stem depth. Use the official Version 2 listing to establish the product identity, then ask for a dimensioned profile drawing if those measurements determine your purchase. The low-profile keycap compatibility guide provides a worksheet for those missing dimensions and interfaces.
Keep the shape question separate from the material question. Keychron has distinct double-shot PBT, dye-sub PBT, and ABS LSA listings, with different legend and lighting specifications. Those differences appear in the comparison below; the acronym alone cannot answer them.
KeebFinder’s August 19, 2025 roundup classifies Keychron LSA Version 2 as LSA/low-profile sculpted and lists PBT, double-shot construction, and ANSI layout coverage. That classification is useful for identifying the set. It is not a dimensioned row drawing or an independent measurement of the profile.
The available source information does not establish exact row heights, row angles, or a uniform-row arrangement for these products. If you plan to move caps between rows, request the maker’s row map rather than assuming every position uses the same shape.
Which LSA keycaps product are you buying?
Use the complete product name to keep these options separate. The table compares documented identity and specifications; it does not rank typing feel or durability.
| Product | Material and legends | Mount and lighting | Buying implication |
|---|---|---|---|
| Keychron Low Profile Double Shot PBT LSA Version 2 | Double-shot PBT | MX-style stem; legends do not transmit backlight, per Keychron Malaysia’s technical specifications | Check Version 2 board support and the selected full-set contents. |
| Keychron Low Profile Dye-Sub PBT LSA Full Set | PBT with dye-sublimated legends | MX-style stem; non-shine-through legends, per the official dye-sub specifications | Use this product’s own ANSI compatibility list. |
| Keychron Low Profile ABS LSA Full Set | ABS | MX-style stem; shine-through legends, per the official ABS specifications | Consider it when illuminated legends are a requirement, subject to exact board support. |
| 3dkeycap LSA split set | 3D-printed resin; no-legends or standard-legends selections | Seller labels the switch type “MX Low-Profile”; confirm lighting for the selected resin and legend option | Check the selected split layout and package directly with 3dkeycap. |
For the molded Version 2 set, the Keychron listing identifies Full Set (133 Keys) and the Knight selection with SKU PBT-58. Read PBT-58 as the product code; the package is described as 133 keys. Preserve the version, color, and SKU when asking a seller to confirm an offer.
The Version 2 lighting specification above comes from Keychron’s Malaysian product record. It supports the technical comparison, without establishing US stock, delivery, return, or warranty terms.
Match the exact Keychron keyboard revision
For Version 2 PBT, Keychron names K1 Version 6, K3 Version 3, K5 Version 2, and K Pro, K Max, and S series low-profile ANSI keyboards in its compatibility statement. Keep both qualifiers—low-profile and ANSI—attached to that statement. A familiar series name by itself is insufficient identification. See the Version 2 compatibility information. The Keychron K3 keycap generation guide develops the K3 version distinctions.
The same record excludes K1 versions 1–5, K1 SE, K5 SE, K7, and legacy K3/K5 entries. Its broad older-model wording should be read alongside its explicit inclusion of K3 Version 3 and K5 Version 2. If your keyboard is identified only as “K3” or “K5,” establish the revision before deciding.
A practical comparison:
- K3 Version 3 with an ANSI layout: explicitly named in the Version 2 support statement; continue to the kit-content check.
- K1 Version 5: explicitly excluded from Version 2 support.
- A keyboard outside the named support: request confirmation for the exact keyboard and switches before treating the set as a fit.
These conclusions apply to Version 2 PBT. Check the separate dye-sub or ABS compatibility list if you change products.
Also distinguish the keyboard’s available layouts from the keycap kit’s coverage. KeebFinder’s roundup lists multiple regional layouts for its K3 V3 keyboard entry while classifying the Version 2 keycap set as ANSI. That combination does not establish ISO coverage for the caps. Use the set-specific classification as a prompt to inspect your selected kit.
Use this fit and kit coverage worksheet
Complete this worksheet with your keyboard information and the selected set’s kit diagram. For an unlisted board, ask the seller to resolve any unknown mounting or clearance detail before ordering. An MX-style stem description supplies one field; it does not answer the remaining questions.
The Version 2 regional specifications and 3dkeycap’s switch description provide starting points, but the supplied information contains no dimensioned stabilizer or clearance drawings.
| Check | Record or compare | What resolves the check |
|---|---|---|
| Keyboard identity | Full model, revision, and ANSI or other layout | Exact manufacturer support, or written confirmation for your configuration |
| Switch interface | Exact switch model and cap mounting interface | Confirmation for that switch and keycap product |
| Row placement | Required key positions and the set’s row assignments | A row map showing the required caps in their intended positions |
| Key widths | Enter, both Shift keys, bottom-row modifiers, and other required widths | Matching widths and quantities in the selected kit diagram |
| Spacebar and stabilizers | Spacebar width and mounting positions for supported larger keys | Matching mounting positions documented by the maker or seller |
| Clearance | Cap underside, seating depth, and surrounding keyboard structure | A relevant drawing or explicit confirmation for the complete configuration |
| Package contents | Every required cap, including split-layout or specialty keys | An itemized selected kit with no unresolved missing keys |
Request dimensions with units, and have both parties identify the same keys and mounting points. A top-view product photo can help identify legends, but request underside information when the unresolved question concerns mounting positions.
For example, an ANSI K3 Version 3 owner considering Knight Version 2 can record the named keyboard support and Full Set (133 Keys) identity from Keychron. The next task is to compare the selected kit diagram with the keys required on that board. If the offer changes to another version or material, repeat the compatibility check using that product’s documentation.
Check the resin split set as a separate product
The 3dkeycap LSA page credits designer Szymon Wysocki and describes resin caps that are 3D printed and finished in Canada. In the captured page, layout selectors offered Lily58 and Corne, alongside resin colors and no-legends or standard-legends choices. For that printed product, apply the 3D-printed keycap buying checks to its own material and finish.
The description also mentions Ferris-Sweep and custom requests. Those text mentions do not establish that a complete Ferris-Sweep package is currently selectable or define exactly which caps a custom order includes. Before ordering, ask for the itemized package corresponding to your chosen layout.
The seller labels the switch type “MX Low-Profile.” The captured page does not provide dimensioned row-height, pitch, stem-depth, or stabilizer-position specifications. Its broad compatibility and comfort language therefore cannot settle fit for an arbitrary split keyboard.
For this option, send the seller your exact board revision, switch model, layout, required key positions, and legend choice. Request confirmation of the supplied caps and any mounting details relevant to your build. Treat customization as a discussion to complete before payment.
Verify the selected offer before paying
The captured Amazon Knight catalog page identifies a Keychron double-shot low-profile PBT LSA full set. However, it does not establish a selected seller, condition, complete kit, or applicable return terms. It also displays an unmatched-options message and separately priced related products.
Use that catalog identity to check what an offer claims to contain. Prices attached to nearby YMDK, OSA, XDA, or Gateron items do not establish the price of the Knight set.
Before paying, verify:
- The exact version, color, package, and seller selected in the cart.
- The delivered total for your US address and the stated shipping timing.
- Whether the order is stocked, backordered, or made to order.
- The return and cancellation terms that apply to that particular order.
For a custom resin package, ask whether the selected layout, color, or legends affect cancellation or return eligibility. Keep the seller’s written fit confirmation with the order details. Current prices, inventory, delivery dates, and return eligibility are not established by this guide.
Frequently asked questions
Are LSA keycaps a uniform profile?
A uniform-row arrangement is not established by the available specifications. Keychron expands LSA as Low Profile Spherical Angled, and KeebFinder classifies Version 2 as low-profile sculpted. Neither description supplies measured row geometry. Request a row map and dimensioned side view if rearranging caps matters to your build. See the profile classification.
Will Version 2 PBT legends light up with RGB?
Keychron Malaysia’s Version 2 specifications state that backlight does not shine through the legends. If illuminated legends are a requirement, investigate the separate ABS LSA set and check its own compatibility list. The lighting distinction is documented in the Version 2 specifications and ABS specifications.
Does a 133-key full set cover every keyboard?
The 133-key count identifies the selected Version 2 package, while Keychron separately names compatible low-profile ANSI keyboards and exclusions. Use both pieces of information. For a different layout or an unlisted board, request the kit diagram and confirmation of every required key rather than deciding from the count alone. See Keychron’s Version 2 listing.
Choose your next step
For LSA keycaps, make the purchase decision in this order: identify the product, match the keyboard revision, confirm lighting, and complete the fit worksheet. For a supported Keychron configuration, start with the official Version 2 listing and its selected kit. For a resin split set, request a complete package and fit confirmation from 3dkeycap before ordering.
